Schematic review closed
10BASE-T1S MAC-PHY HAT
Raspberry Pi HAT based on the Analog Devices ADIN1140 10BASE-T1S MAC-PHY, with SPI host interface, PLCA support and selectable bus termination.
View designBE-IIS Schematic Review
These schematic reviews have concluded. The design files remain available for reference; the review campaign and its free-HAT offer are closed.
Schematic review closed
16-channel isolated 卤10 V ADC HAT
16-bit, 16-channel Raspberry Pi ADC HAT based on the TI ADS8686S, with an isolated 卤10 V field side.
View design
Schematic review closed
10BASE-T1S MAC-PHY HAT ONSEMI
Raspberry Pi HAT based on the onsemi T30HM1TS2500 10BASE-T1S MAC-PHY, with SPI host interface, PLCA support and selectable bus termination.
View design
